Quincy QGS-5-HPD Oil Lubricated Rotary Screw Air Compressor
Product Description
Used 2018 Quincy model QGS-5-HPD oil lubricated rotary screw air compressor package with low sound enclosure, gauge control panel, start/stop control, tri-voltage TEFC motor (currently set at 230/3/60), full voltage starter, refrigerated air dryer (requires separate 115v power supply, 2.7 amps), and 60-gallon horizontal air receiver with pressure relief valve and manual tank drain valve.
Product Specifications
- Motor Size: 5 Horsepower
- Air Delivery: 6.6 CFM @ 150 PSIG
- Voltage: 208 / 230 / 460-3-60 (18.4/15.8/7.9 amps)
- Air Connection: ½” NPT
- Dimensions: 56”L x 26”W x 50”H
- Approximate Weight: 437 Lbs.
- Air Dryer Refrigerant Type: R134a
- Reference Zorn Part Number: 149-005-4752
